AN SFX REVOLUTION
The V SFX Platinum is leading the industry as the first SFX unit to acheive 1300W, and includes top-tier features such as full compatibility with ATX 3.0 and both ITX and ATX cases, and new miniaturization technology that enhances thermal performance and increases power density.
HIGH POWER DENSITY
Improved material engineering techniques, manufacturing processes, and miniaturization technology have ensured the V SFX Platinum has one of the highest power densities in the industry.
MINI BUT MIGHTY
Flat copper wiring on the DC-DC choke, flat transformer piling, an aluminum plate dissipation structure on the full-bridge LLC, and advanced manufacturing processes enhance overall miniaturization.
ENHANCED DISSIPATION
The transformer, rectifier, full-bridge LLC, and EMI-inhibiting amorphous metal materials are fully integrated for advanced performance and heat dissipation.
FULL & FLEXIBLE COMPATIBILITY
With an ATX bracket, ATX 3.0 support, and GPU compatibility with both the 40 series and previous cards, the V SFX Platinum works with both ATX and mini-ITX cases.
|
|
|
|
| ATX Version |
ATX 3.0, SFX 12V Ver. 3.42 |
|
|
|
|
|
|
|
| Input Current |
7.7A (Max.) |
|
|
|
| Dimensions (L x W x H) |
100 x 125 x 63.5 mm |
|
|
|
|
|
| Efficiency |
≥ 94% @ Typical Load |
|
| 80 PLUS Rating |
80 PLUS Platinum EU 230V |
|
|
|
| Operating Temperature |
0-50°C |
|
| Power Good Signal |
100 – 150 ms |
|
| Hold Up Time |
≥16ms at 60% Load |
|
|
|
| Protections |
OVP, OPP, SCP, OCP, UVP, OTP, Surge and Inrush Protection |
|
| Regulatory |
TUV, cTUVus, CE, FCC, BSMI, CCC, EAC, UKCA |
|
|
|
|
|
|
|
|
|
| Peripheral 4 Pin Connectors |
4 |
|
| PCI-e 6+2 Pin Connectors |
3 |
|
|
|
|
|
|
|
|
|
