Description
| Model | CS-DL06-R100-WBCP-GR |
|---|---|
| Material and Specification | |
| Panel Material | Aluminum Alloy |
| Panel Size | 331 × 40 × 25.8 mm |
| Color | Metallic Grey |
| Lock Body Type | Lift-Up Lock Body |
| Lock Cylinder | 2885 / 3585 / 4585 |
| Weatherproof | IP55 (Front Panel) |
| Emergency Charging | Type-C |
| Working Power | 1,450 mAh Rechargeable Lithium Battery |
| Technical Specification | |
| Unlocking Methods | Fingerprint, Passcodes, Proximity Card, Mechanical key, Bluetooth Remote Control,Bluetooth Key via the EZVIZ App, Temporary Codes, Remote Unlocking |
| User Capacity | 50 pcs |
| Fingerprint Capacity | 50 pcs |
| Passcode Capacity | 50 pcs |
| Card Capacity | 50 pcs |
| Communication Methods | 2.4GHz Wi-Fi, Bluetooth |
| Temporary Access Codes | Supports |
| Anti-Peeping Codes | Supports, Max. 20 digits |
| Low Battery Warning | Supports |
| Privacy Mode | Supports |
| User Management | Supports |
| Real Time Notification | Supports |
| Anti-Test Locking | Supports
Five failed attempts in five minutes trigger a three-minute lockout. |
| Anti-Tamper Alarm | Supports |
| Remote Control | Supports |
| Supported Door Thickness | 30-120 mm |
| Working Temperature | -10°C~55°C |
| Operating Humidity | 10%~95% |
| In the box | |
| In the box | – DL06 Front Panel |
| – DL06 Rear Panel | |
| – Hole Templet | |
| – Lock Body | |
| – Standard Screw Bag | |
| – Lithium Battery | |
| – Mechanical Key × 2 | |
| – Square Rod | |
| – Proximity Card × 2 | |
| – Screwdriver | |
| – Regulatory Information | |
| – Quick Start Guide | |
