The Hikvision DS-QAE0A60G1-VB is a compact 60W analog audio amplifier designed for small and medium-scale public address (PA) systems. It provides flexible audio input options including Bluetooth playback, USB flash drive audio, microphone input, and RCA input, making it suitable for announcements, background music, and voice broadcasting applications.
The amplifier supports two-zone audio output management, allowing independent volume adjustment for different areas. It provides 100V constant voltage output for distributed speaker systems and also supports low-impedance speaker connections (4–8Ω), offering flexibility for various installation requirements.
The DS-QAE0A60G1-VB features a built-in Bluetooth module, USB playback support, microphone mixing, and RCA audio connectivity. Its integrated design includes protection functions such as short-circuit protection, over-current protection, over-temperature protection, surge protection, anti-static protection, and electrical shock protection, ensuring reliable operation in professional audio environments.
With its compact design and easy operation, this amplifier is suitable for schools, offices, retail stores, meeting rooms, hotels, factories, and small commercial PA systems requiring clear voice announcements and background audio.
Short Specifications
- Product Type: Analog PA Amplifier
- Rated Power: 60 W
- Power Supply: 24 VDC
- Audio Zones: 2 zones
- Audio Inputs:
- 1 × Microphone input
- 1 × USB 2.0
- 1 × RCA input
- Bluetooth 5.3
- Audio Outputs:
- 2 × 100V constant voltage output
- 2 × 4–8Ω low impedance output (30W max each)
- RCA output
- Frequency Response:
- USB/Bluetooth: 20 Hz – 20 kHz
- MIC/RCA: 20 Hz – 8 kHz
- THD: ≤1%
- SNR: ≥100 dB
- Bluetooth Range: Approx. 10 m
- Cascade Support: Up to 3 amplifiers via RCA
- Protection: Short circuit, over-current, over-temperature, surge, anti-static, electric shock protection
- Material: Plastic
- Dimensions: 190.8 × 230.8 × 51.2 mm
- Weight: Approx. 1.45 kg
- Operating Temperature: -10°C to 55°C
Main Features
- 60W two-zone analog amplifier
- Bluetooth and USB music playback
- Microphone announcement support
- 100V speaker line output
- Independent zone volume adjustment
- Multiple safety protection functions
- Compact design for easy installation
Recommended Applications:
- Offices
- Schools
- Shops and retail outlets
- Hotels
- Meeting rooms
- Small public address systems
