HIKVision Wireless PIR Detector, Detection range: 15m

The Hikvision DS-PDP15P-EG2-WE is a fully supervised wireless passive infrared (PIR) detector for the AX PRO alarm system. Designed for residential and commercial indoor applications, it delivers dependable motion detection with a 15 m coverage and 85.9° detection angle while ignoring pets weighing up to 30 kg, minimizing false alarms.

The detector incorporates SEC (Smart Environmental Control) technology with advanced digital signal processing, 3D optics, digital temperature compensation, and sealed optics for stable performance in varying environmental conditions. It communicates using Tri-X 868 MHz two-way wireless technology with AES-128 encryption, frequency hopping, and a wireless transmission range of up to 1.6 km (open area). Powered by a single CR123A lithium battery, it offers up to 5 years of battery life. Additional features include front and rear tamper protection, signal strength indication, remote configuration via the Hik-Connect app, and multiple enrollment methods for quick installation.

Key Specifications

• Passive Infrared (PIR) motion detector
• Detection range: 15 m
• Detection angle: 85.9°
• 52 detection zones
• 30 kg pet immunity
• Detectable speed: 0.3–2.0 m/s
• SEC (Smart Environmental Control) with digital signal processing
• Digital temperature compensation
• White light filter: 6,500 lux
• Front and rear tamper protection
• 868 MHz Tri-X two-way wireless communication
• AES-128 encrypted transmission
• Wireless range: Up to 1.6 km (open area)
• Battery: 1 × CR123A 3 V lithium
• Battery life: Up to 5 years
• Operating temperature: -10°C to +55°C
• Dimensions: 65.5 × 103 × 48.5 mm
• Weight: 128 g
