HIKVISION Wireless Repeater

The Hikvision DS-PR1-WE is a wireless signal repeater for the AX PRO intrusion alarm system, designed to expand wireless coverage in residential, commercial, and industrial security installations. It receives and retransmits signals between the AX PRO control panel and connected wireless detectors, helping maintain stable communication in areas where direct RF coverage is limited.

The repeater supports 868 MHz two-way wireless communication using Hikvision’s Tri-X and Cam-X wireless protocols, providing secure and reliable data transmission with AES-128 encryption. It supports automatic pairing and can automatically discover and connect compatible devices such as PIRCAM detectors and smoke detectors.

The DS-PR1-WE features LED status indicators for easy monitoring, front and rear tamper protection, and a built-in rechargeable lithium battery that provides backup operation during mains power failure. With a wireless transmission range of up to 1.6 km in open area, it is suitable for extending AX PRO systems in larger buildings or installations with challenging wireless environments.

Key Specifications

• Product type: Wireless Repeater
• Compatible system: Hikvision AX PRO
• Wireless protocols:
  • Tri-X
  • Cam-X
• Communication: 868 MHz two-way wireless
• Encryption: AES-128
• RF range: Up to 1.6 km (open area)
• Automatic pairing: Supported
• Supports connection of up to 8 PIRCAM or smoke detectors
• LED status display:
  • Registration / signal status
  • Power status
  • Fault indication
• Tamper protection: Front and rear
• Power supply: 100–240 VAC
• Backup battery: Built-in lithium battery
• Battery backup: Up to 35 hours (depending on model/version and conditions)
• Installation: Wall mounting
• Operating temperature: -10°C to +55°C
• Operating humidity: 10%–90%
• Dimensions: 150 × 150 × 25 mm
• Weight: Approx. 372 g

Applications

• Large homes and villas
• Offices and commercial buildings
• Warehouses and industrial sites
• Installations requiring extended AX PRO wireless coverage
• Areas with weak RF signal between detectors and alarm panel
