| Standards and Protocols | Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11ax/n/b/g 2.4 GHz |
|---|---|
| WiFi Speeds | AX3000 5 GHz: 2402 Mbps (802.11ax) 2.4 GHz: 574 Mbps (802.11ax) |
| WiFi Range | 1-3 Bedroom Houses (1-pack)
TP-Link Mesh Technology 4× LTE/5G internal antennas + 2× Wi-Fi internal antennas SIM Card Format: Nano-SIM |
| WiFi Capacity | High
Dual-Band MU-MIMO OFDMA 4 Streams |
| Working Modes | 5G/4G Router, Router, Access Point |
| Network Security | SPI Firewall Access ControlHomeShield Security Real-Time IoT Protection |
|---|---|
| Guest Network | 1× 5 GHz Guest Network 1× 2.4 GHz Guest Network |
| WiFi Encryption | WPA-Personal WPA2-Personal WPA3-Personal |
| Ports and Connections | 1× 2.5 Gigabit port + 2× 1 Gigabit ports (WAN/LAN auto-sensing)Compatibility 5G: N1/N3/N5/N7/N8/N20/N28/N38/N40/N41/N77/N78 4G FDD-LTE: B1/B3/B5/B7/B8/B20/B28 4G TDD-LTE: B38/B40/B41/B42/B43 3G: B1/B5/B8 |
|---|---|
| Protocols | IPv4 IPv6 |
|---|---|
| Service Kit | HomeShield Learn More> |
| WAN Types | Dynamic IP Static IP PPPoE L2TP PPTP |
| Quality of Service | HomeShield QoS
QoS by Device |
| Cloud Service | OTA Firmware Upgrade TP-Link ID DDNS |
| NAT Forwarding | Port Forwarding UPnP |
| IPTV | IGMP Proxy IGMP Snooping Bridge Tag VLAN |
| DHCP | Address Reservation DHCP Client List Server |
| DDNS | TP-Link |
| Management Features | Deco App |
| Network Services Enabled by Default | Web Server Manage and configure device through web (HTTP/HTTPS) • Port: 80/443 Protocol: TCP DNS DHCP Server App management |
|---|---|
| WiFi Transmission Power | CE: ≤20 dBm (2.4 GHz), ≤23 dBm (5 GHz) |
|---|---|
| Dimensions (W×D×H) | 8.3 × 5.1 × 4.8 in (210.5 × 130 × 123mm) |
|---|---|
| Certification | RoHS, CE, RCM |
|---|---|
| Package Content | 1-pack 1 Deco X50-5G unit 1 RJ45 Ethernet Cable 1 Power Adapter Quick Installation Guide |
| Environment | Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~60°C (-40°F~140°F) Operating Humidity: 10%~90%RH Storage Humidity: 5%~90%RH |
