HIKVision 5 Ghz, 867 Mbps, 5 Km Outdoor Wireless Bridge

The Hikvision DS-3WF02C-5AC/O is a professional outdoor 5 GHz wireless bridge system designed to provide reliable point-to-point (PTP) and point-to-multipoint (PTMP) network connections for security surveillance and industrial applications. It enables high-speed transmission of video and network data between locations without the need for physical cabling.

Using IEEE 802.11a/n/ac wireless technology, the device provides an air interface transmission rate of up to 867 Mbps and supports long-range wireless communication of up to 5 km under suitable installation conditions. It is suitable for applications such as IP camera links, remote buildings, industrial sites, railway systems, power infrastructure, and rural network coverage.

The DS-3WF02C-5AC/O features integrated directional antenna technology with high-gain performance, helping maintain stable wireless connections over long distances. It supports TDMA technology, which improves communication efficiency when multiple devices share the wireless environment.

The device includes two Gigabit RJ45 Ethernet ports, allowing high-speed wired connections to cameras, switches, or network equipment. Power can be supplied through 12–24 VDC passive PoE, simplifying installation by allowing power and data transmission through a single cable.

For easier deployment, the wireless bridge supports quick matching through DIP switch configuration, signal strength indicators for alignment, and centralized management options. It supports security features such as WPA2-PSK encryption and management through web interface and Hikvision management platforms.

Designed for outdoor environments, the DS-3WF02C-5AC/O operates in temperatures from approximately -30°C to 70°C, making it suitable for harsh outdoor installations such as surveillance towers, farms, warehouses, construction sites, and remote facilities.

Key Specifications

• Product Type: Outdoor Wireless Bridge / CPE
• Wireless Standard: IEEE 802.11a/n/ac
• Frequency Band: 5 GHz
• Maximum Wireless Rate: Up to 867 Mbps
• Transmission Distance: Up to 5 km
• Wireless Modes:
  • Point-to-Point (PTP)
  • Point-to-Multipoint (PTMP)
• Antenna Gain: Up to 12 dBi (model/version dependent)
• Antenna Beamwidth: Approx. 35°
• LAN Ports: 2 × Gigabit RJ45 Ethernet
• Power Supply: 12–24 VDC Passive PoE
• Channel Width: 20 / 40 / 80 MHz
• Wireless Features:
  • TDMA
  • DFS
  • TPC
  • Automatic/manual channel selection
• Security: WPA2-PSK
• Management: Web interface, Hikvision management tools
• Operating Temperature: -30°C to 70°C
• Installation: Outdoor pole mounting
• Applications:
  • CCTV wireless links
  • Building-to-building networking
  • Farms and rural sites
  • Industrial facilities
  • Remote offices
  • Traffic and infrastructure monitoring
