HIKVision WiFi Dongle for DVR/NVR

The Hikvision DS-3WR3X-1 is a compact Wi-Fi 6 Nano USB adapter designed specifically for Hikvision video recorders that require wireless network access. It allows compatible DVR/NVR systems to connect to a Wi-Fi network, simplifying installation in locations where running network cables is difficult or not practical.

Supporting the latest IEEE 802.11ax Wi-Fi 6 standard, along with backward compatibility for 802.11b/g/n, the adapter provides improved wireless efficiency, stability, and compatibility compared with older Wi-Fi standards. It operates on the 2.4 GHz frequency band and supports wireless modes including Station Mode and Soft AP Mode.

The DS-3WR3X-1 uses a USB 2.0 interface with a compact nano design measuring approximately 21 × 15 × 7.7 mm, making it easy to install directly into the recorder’s USB port without taking up much space. Its internal antenna provides a discreet and simple wireless connection solution.

The adapter supports wireless security protocols including WPA-PSK and WPA2-PSK encryption to help protect network communication. It is designed for easy deployment with driver-free plug-and-play installation on compatible Hikvision recorders.

Key Specifications

• Product Type: Wi-Fi 6 Nano USB Wireless Adapter
• Wireless Standard:
  • IEEE 802.11ax
  • IEEE 802.11b/g/n
• Frequency: 2.4 GHz
• Data Rate: Up to 20 Mbps (for recorder connection)
• Interface: USB 2.0
• Antenna: Built-in internal antenna
• Wireless Modes:
  • Station Mode
  • Soft AP Mode
• Security:
  • WPA-PSK
  • WPA2-PSK
• Installation: Plug-and-play, driver-free
• Dimensions: 21 × 15 × 7.7 mm
• Operating Temperature: 0°C to 45°C
• Operating Humidity: 10% to 90% RH (non-condensing)
• Applications:
  • Hikvision DVR wireless networking
  • Compatible recorder installations
  • Small CCTV systems where wired LAN connection is unavailable
