Description
|
Interfaces
|
16 x 10/100/1000BASE-T ports 4 x Combo 10/100/1000BASE-T/SFP ports |
|---|---|
|
Switch Capacity
|
40 Gbps |
|
Max. Packet Forwarding Rate
|
29.8 Mpps |
|
Power Input
|
100 to 240 V AC |
|
Dimensions
|
280mm x 180 mm x 44mm |
|
Weight
|
1.75 kg |
|
Temperature
|
Operating: -5 to 50° C (23 to 122° F) Storage -20 – 70°C |
|
Humidity
|
Operating: 0% – 95% RH Storage: 0% – 95% RH |
|
Operating Altitude
|
1500 m |
|
Max Power Consumption
|
13.08 W/100 V 13.02 W/240 V |
|
Maximum Heat Dissipation
|
44.62 BTU/hr (100V) 44.41 BTU/hr (240V) |
|
Acoustic
|
0 dB |
|
MTBF
|
1,087,100 hours |
|
CPU Speed
|
500MHz |
|
Flash Memory Size
|
32 MB |
|
DRAM Size
|
DDR3 128MB |
|
Packet Buffer Size
|
4.1Mbits |
|
FAN
|
Fanless |
|
Standby Power Consumption
|
5.47 W/100V 5.56 W/240V |
