HIKVision AC1200 Wireless Router

The Hikvision DS-3WR12C-E is a compact dual-band AC1200 wireless router designed to provide stable and high-speed Wi-Fi connectivity for homes, offices, and small business environments. It supports the IEEE 802.11ac Wave 2 standard on 5 GHz and IEEE 802.11b/g/n on 2.4 GHz, allowing users to enjoy faster wireless performance and improved network efficiency.

The router provides a combined wireless speed of up to 1200 Mbps, delivering up to 866 Mbps on the 5 GHz band and 300 Mbps on the 2.4 GHz band. The dual-band design allows high-bandwidth activities such as HD/4K video streaming, online gaming, and network surveillance applications while maintaining stable connections for everyday devices.

Equipped with four external 5 dBi high-gain antennas, the DS-3WR12C-E improves wireless coverage and signal stability. It supports MU-MIMO technology and beamforming, helping optimize communication with multiple connected devices and improving overall Wi-Fi performance.

The router includes one 10/100 Mbps WAN port and three 10/100 Mbps LAN ports for wired network connections. It supports multiple operating modes, including wireless router mode, repeater mode, client + AP mode, WISP mode, and AP mode, providing flexible deployment options for different network requirements.

For security and management, the DS-3WR12C-E supports WPA/WPA2 encryption, SSID hiding, guest network configuration, Wi-Fi scheduling, signal adjustment, DHCP server functions, and web-based configuration. It can be easily managed for home and small office network environments.

Key Specifications

• Product Type: AC1200 Dual-Band Wi-Fi Router
• Wireless Standard:
  • IEEE 802.11ac Wave 2 (5 GHz)
  • IEEE 802.11b/g/n (2.4 GHz)
• Wireless Speed: Up to 1200 Mbps
  • 5 GHz: 866 Mbps
  • 2.4 GHz: 300 Mbps
• Frequency Bands: 2.4 GHz + 5 GHz
• Antennas: 4 × External high-gain antennas
• Antenna Gain: 5 dBi
• Wireless Features:
  • MU-MIMO
  • Beamforming
  • Dual-band smart switching
• Network Ports:
  • 1 × 10/100 Mbps WAN port
  • 3 × 10/100 Mbps LAN ports
• Operating Modes:
  • Wireless Router Mode
  • Repeater Mode
  • Client + AP Mode
  • WISP Mode
  • AP Mode
• Security:
  • WPA-PSK
  • WPA2-PSK
  • WPA/WPA2
  • Hide SSID
• Management: Web interface / APP management
• Power Supply: 9 VDC, 1 A adapter
• Maximum Power Consumption: ≤ 9 W
• Installation: Desktop / wall mounting
• Operating Temperature: 0°C to 40°C
• Applications:
  • Homes
  • Small offices
  • Shops
  • Small CCTV networks
  • Wireless internet sharing
  • Wi-Fi extension projects
