HIKVISION Aluminium NO Touch Push Button
The Hikvision DS-K7P03 is a professional exit button / request-to-exit device designed for access control systems. It features a stainless-steel panel, NO/NC/COM relay output, LED indication, and a durable design tested for long-term operation. It is suitable for narrow door frames, access-controlled doors, offices, commercial buildings, and security areas.
₨1,400 inc. Vat
Payment Option
Credit by Rogers Finance: ₨1,610
Apply with Rogers code - RTDL01
Credit by Rogers Finance: ₨1,610
Apply with Rogers code - RTDL01
11
People watching this product now!
Description
- New version of DS-K7P03, there is “/T” in the label
- Stainless steel panel, Led Indicator
- Dimension(L×W×H): 86×86×25.7mm(3.39×3.39×1.01″).
Description
|
General
|
|
|
Working Temperature
|
-20 °C to 50 °C (-4 °F to 122 °F)
|
|
Working Humidity
|
0 to 95% (relative humidity)
|
|
Dimension (L×W×H)
|
86 mm × 86 mm × 25.7 mm (3.39″ × 3.39″ × 1.01″).
|
|
Current Rating
|
1 A@30 VDC
|
|
Output Contact
|
NO/NC/COM contact
|
|
Aging Test
|
Already passed 1 million times aging test
|
|
Panel
|
Stainless steel
|
|
Product Weight
|
0.2 kg (0.44 lb)
|
|
Suitable Doors
|
All kinds of narrow doorframes
|
